Technical parameters for the signal reception of the TV channel «Belarus 24» from the ABS-2А satellite:

        • satellite: ABS-2A
        • orbital position 75 °E
        • downlink frequency 11 665 МGz
        • polarization: vertical
        • symbol rate 44 922 kSymb/s
        • FEC: 5/6
        • transponder   FSS4
        • video  DVB-S / MPEG-2 / SD
        • channel name BELARUS 24

Coverage area of the ABS-2A satellite

ABS-2 Coverage Area

Operators of cable and satellite television of the Russian Federation should apply regarding the issues of connection and transmission of the TV channel «Belarus 24» to the official distributor SIGNAL MEDIA (LLC «Signal») by e-mail: contact@signalmedia.ru or by phone: +7 (495) 620-98 -36.


Technical parameters for receiving free-to-air  TV channel "Belarus 24" on Express AM 8 satellite (Western Europe):

  • Satellite name   Express AM 8
  • Orbital position 14°W
  • Band Ku
  • Bitrate 6 Мбит/с
  • Downlink frequency 11 633 MGz
  • Beam fixed 1
  • Polarization vertical
  • Symbol rate 13881,31 kSymb/s
  • Modulation QPSK
  • FEC 1/2
  • SID 1
  • VPID 200
  • Transponder BD10
  • Video DVB-S2 / MPEG-4 / HD 1080
  • Channel name BELARUS 24



Technical parameters for receiving free-to-air  TV channel "Belarus 24" on Express AM 8 satellite (Latin America):

  • Satellite name   Express AM 8
  • Orbital position 14°W
  • Band C
  • Bitrate 3.5 Мбит/с
  • Downlink frequency 3 956  MGz
  • Polarization circular
  • Symbol rate 1570 kSymb/s
  • Modulation 8PSK
  • FEC 3/4
  • Video  DVB-S2/MPEG-4 / SD 480/60i
  • Channel name BELARUS 24

Fixed 2.jpg



Technical parameters for receiving free-to-air  TV channel "Belarus 24" on Azerspace 1 satellite


  • Satellite name   Azerspace 1
  • Orbital position 46 °E
  • Band Ku
  • Bitrate 6 Мбит/с
  • Downlink frequency 11 024 MGz
  • Beam Central Asia
  • Polarization horizontal
  • Symbol rate 16 500 kSymb/s
  • Modulation 8PSK
  • FEC  3/4
  • SID 3
  • VPID  1303
  • Transponder 3К
  • Video DVB-S2 / MPEG-4 /НD
  • Channel name BELARUS 24


Enjoy watching!
